Processor
Processor typeIntel®
Processor family5th Gen Intel® Xeon® Scalable Processors and 4th Gen Intel® Xeon® Scalable Processors
Processor number1 or 2
Processor core available16 to 60 core, depending on processor
Processor speed3.1 GHz maximum, depending on processor
Processor cache22.5 MB to 112.5 MB L3, depending on processor
Server Memory
Memory typeHPE DDR5 Smart Memory
Maximum memory8 TB with 256 GB DDR5
Memory slots32
Memory protection featuresRAS – Advanced ECC, online spare, mirroring, combined channel (lockstep) functionality, and HPE Fast Fault Tolerant Memory (ADDDC); Intel Optane Persistent Memory
Server Accelerator
AcceleratorsOptional
Server Cooling
System fan featuresHot-plug redundant fans, Standard Fan Kit or High Performance Fan Kit, depending on model
Server Expansions
Expansion slotsUp to 8 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs
Server Form Factor
Form factor2U Rack
Server Controllers
Network controller1 Gb, 10 Gb, 10/25 Gb, 100 Gb, or 200 Gb, in PCIe adapter or OCP 3.0 form factor, for detailed descriptions reference the QuickSpecs
Storage controllerHPE SR932i-p and/or HPE MR216i-o and/or HPE MR416i-o and/or HPE MR216i-p and/or HPE MR416i-p and/or HPE MR408i-o, for detailed descriptions reference the QuickSpecs
Server Drives
Drive supported8 or 12 LFF SAS/SATA/SSD 8, 16, or 24 SFF SAS/SATA/SSD, depending on configuration. 6 SFF rear drive optional or or 2 SFF rear-drive optional, 20 SFF NVMe optional, NVMe support via Express Bay will limit maximum drive capacity, depending on model.
Optical drive typeOptional DVD-ROM via Universal Media Bay External support only
Server Power
Power supply type800W, 1000W, or 1600W Dual hot-plug redundant 1+1 HPE Flexible Slot Power Supplies, depending on model
Management Software
Infrastructure managementHPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE OneView Advanced (optional, requires licenses), and HPE COM
Security
SecurityHPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit.
